High-Speed Wireless PerformanceDelivers up to 300Mbps on 5GHz frequency with a built-in 13dBi dual-polarized directional antenna for extended range and stable connections.
Robust Outdoor DesignFeatures IPX5 waterproof enclosure with 15kV ESD and 6kV lightning protection, ensuring reliable operation in harsh weather conditions.
Advanced Pharos MAXtream TDMA TechnologyImproves throughput, capacity, and latency for efficient point-to-multipoint wireless networking.
Versatile Operation ModesSupports AP, Client, Bridge, Repeater, AP Router, and AP Client Router (WISP) modes for flexible deployment.
₹6,999
Inclusive of all taxes.
Add items to your cart. Checkout will open in a future update.
Brandtp-link
SKUTPL-CPE510-5G-300-13DBI
Description
The TP-Link CPE510 is a high-performance outdoor Customer Premises Equipment (CPE) designed for reliable wireless networking in outdoor environments. Operating on the 5GHz frequency band, it delivers wireless speeds up to 300Mbps, making it suitable for long-range point-to-point and point-to-multipoint applications. The device features a built-in 13dBi 2x2 dual-polarized directional antenna that ensures focused signal transmission and reception, enhancing coverage and reducing interference.
Equipped with a Qualcomm Atheros Enterprise 560MHz CPU and 64MB DDR2 RAM, the CPE510 offers robust hardware performance. It supports multiple operation modes including AP, Client, Bridge, Repeater, AP Router, and AP Client Router (WISP), providing versatile deployment options. The device incorporates Pharos MAXtream TDMA technology to improve throughput, capacity, and latency, which is ideal for networks with multiple CPEs.
The CPE510 is built for outdoor durability with an ASA stabilized plastic enclosure rated IPX5 for waterproofing, and it includes 15kV ESD and 6kV lightning protection to withstand harsh weather conditions. It supports passive Power over Ethernet (PoE) for flexible installation up to 60 meters and includes dual Ethernet ports with PoE passthrough, grounding terminal, and lightning protection over Ethernet cables.
Management is streamlined through the Pharos Control centralized management system and a user-friendly web interface, allowing remote device discovery, monitoring, firmware upgrades, and network maintenance. Additional features include spectrum analyzer, throughput monitors, speed test tools, and advanced wireless security protocols such as WPA/WPA2 and WEP encryption.
Overall, the TP-Link CPE510 is a reliable and versatile outdoor wireless solution suitable for enterprise and home users requiring stable long-range wireless connectivity.
Product Highlights
High-Speed Wireless PerformanceDelivers up to 300Mbps on 5GHz frequency with a built-in 13dBi dual-polarized directional antenna for extended range and stable connections.
Robust Outdoor DesignFeatures IPX5 waterproof enclosure with 15kV ESD and 6kV lightning protection, ensuring reliable operation in harsh weather conditions.
Advanced Pharos MAXtream TDMA TechnologyImproves throughput, capacity, and latency for efficient point-to-multipoint wireless networking.
Versatile Operation ModesSupports AP, Client, Bridge, Repeater, AP Router, and AP Client Router (WISP) modes for flexible deployment.
Centralized ManagementIncludes Pharos Control software for easy device discovery, monitoring, and firmware upgrades from a single PC.
Power over Ethernet SupportPassive PoE adapter enables installation up to 60 meters with remote reset capability.
Full Specifications
General
| Wireless Speed | 5GHz 300Mbps 5GHz 300Mbps 2.4GHz 300Mbps 2.4GHz 300Mbps |
|---|---|
| Antenna | 16dBi 13dBi 12dBi 9dBi |
| MIMO | √ √ √ √ |
| Coverage Range | 20km+ 15km+ 13km+ 5km+ |
| Compatibility | 802.11a/n 802.11a/n 802.11b/g/n 802.11b/g/n |
| External Antenna Interface | - - - - |
| Weatherproof Enclosure | √(IPX5) √(IPX5) √(IPX5) √(IPX5) |
| Grounding Terminal | √ √ √ √ |
| ESD Protection | 15kV 15kV 15kV 15kV |
| Lightning Protection | 6kV 6kV 6kV 6kV |
| Operation Modes | AP / Client / Bridge / Repeater / AP Client Router (WISP Client) / AP Router Mode |
| Channel Bandwidth | 5/10/20/40MHz 5/10/20/40MHz 5/10/20/40MHz 5/10/20/40MHz |
| MAXtream TDMA Mode | √ √ √ √ |
| Throughtput Monitors | √ √ √ √ |
| Spectrum Analyzer | √ √ √ √ |
| Iperf Speed Test Tool | √ √ √ √ |
| Dimensions( W X D X H ) | 224 x 79 x 60 mm |
| Protection | 15KV ESD Protection 6KV Lightning Protection |
| Management Features | Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server |
| System-level Optimizations | Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog |
| WIRELESS FEATURES Wireless Standards | IEEE 802.11a/n (with Pharos MAXtream disabled) |
| Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds | Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic) |
| Frequency | 5.15~5.85GHz Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used. |
| Button | Remote Reset Button |
| Input | 100-240VAC, 50/60Hz |
| Efficiency | >80% |
| About | Corporate Profile Sustainability Contact Us Privacy Policy |
| Press | News Blog Security Advisory |
| Partners | Partner Program |
| Learning Center | Technology Trends |
Power
| Transmit Power | 27dBm 23dBm 30dBm 27dBm |
|---|---|
| Power Supply | 24 V V |
| Transmit Power Control | Stepping 1dBm Stepping 1dBm Stepping 1dBm Stepping 1dBm |
| Max. Power Consumption | 9.8 Watts Max Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. V |
| SOFTWARE FEATURES Wireless Configurations | Pharos MAXtream TDMA Technology 802.11a/n Modes Selectable Channel Width: 5/10/20/40MHz Automatic Channel Selection Transmission Power Control Dynamic Frequency Selection (DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TK |
| Transmission Power | 23dBm/200mw (Adjustable power by 1dBm) Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used. |
| POE ADAPTER FEATURES Dimensions(W x D x H) | 85.8×43.9×29.7 mm |
| Power Status LEDs | Green |
| Package Content | Outdoor Wireless CPE 24V 0.5A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide |
Connectivity
| Dual Ethernet Ports | √ √ √ √ |
|---|---|
| Lightning Protection over Ethernet Cable | √ √ √ √ |
| Interface | 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1 Grounding Terminal 1 Reset Button |
| Interfaces | 1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data) |
| Output | 24VDC, 0.5A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) |
Network
| PoE Passthrough | √ √ √ √ |
|---|---|
| Pharos Control Supported (Central Network Management Application) | √ √ √ √ |
Performance
| HARDWARE FEATURES Processor | Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc |
|---|---|
| System Tools | Wireless Signal Quality Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute |
Memory & Storage
| Memory | 64MB DDR2 RAM, 8MB Flash |
|---|---|
| Environment | Operating Temperature: -40℃~70℃ (-40℉~158℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
Physical
| Enclosure | Outdoor ASA stabilized plastic material IPX5 waterproof Certification |
|---|
Certifications
| Certifications | CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark |
|---|---|
| OTHERS Certification | CE, FCC, RoHS, IPX5 |
Operating System
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefo |
|---|
